| ENGINE |
| Engine Model |
Horizontal 4 stroke Single cylinder Water cooled Diesel engine. |
| Type |
3 Cylinder, 4 Stroke, Over Head Valve |
| Combustion Chamber |
Direct Injection (DI) |
| Bore |
95mm |
| Stroke |
95mm |
| Displacement |
673.4 cc |
| Compression Ratio |
18:01 |
| Max. Torque |
4.2kg–m/ 1900rpm |
| Max.HP as per IS 13539 1996 |
13.0 HP@2400rpm |
| S.F.C.(Specific Fuel Cons) |
192g/hp/hr |
| Governor System |
Mechanical Centrifugal Type |
| Cooling System |
Condenser Type Thermo Siphon cooling System |
| Starting System |
Hand Cranking |
| Lighting System |
12 volts / 35 watts |
| Std. Pulley (DIA) |
100 mm/optional 120mm |
| Dry Weight |
125 Kgs |
| FUEL SYSTEM |
| Fuel |
High Speed Diesel |
| Fuel Tank Capacity |
11 ltrs. |
| Nozzle |
Multihole (4) |
| LUBRICATING SYSTEM |
| Oil Sump capacity |
2.4 ltrs. |
| Type of Lubricating System |
Force Feed type Trochoid Pump |
| Air Cleaner |
Multistage stage oil bath type with cyclonic per cleaner |
| PERFORMANCE |
| Tilling Width |
600 mm maximum |
| No. of tynes |
18 |
| Tilling Depth |
150mm maximum |
| Plough Depth |
220mm maximum |
| TILLER |
| Model |
CT 85 |
| Type |
Side drive rotary transmission |
| Forward |
6 Speeds |
| Reverse |
2 Speeds |
| Rotary |
2 Speeds ( Optional 4 Speeds) |
| Clutch |
Multiple Plate, Dry disc type |
| Brake |
Hand operated internal expanding metalic Shoe Type. |
| Weight |
280 Kgs. |
| OVERALL DIMENSIONS |
| Length * Width * Height |
2320 mm x 810 mm x 1300 mm |
