| Engine |
Cummins 375HP |
| Type: |
Four-stroke, water-cooled, in-line, dry-liner, direct-injection. |
| Max. Power: |
276kw/2,200rpm |
| Max. Torque: |
1,450N.M/1,300~1,500rpm |
| No. of cylinder: |
6 |
| Bore x Stroke: |
114*145 |
| Displacement: |
8.9 |
| transmission |
Wheels & Tires |
| Model: |
12JS160T |
| Tires: |
11.00-20 |
| Axles - MAN |
| Front: |
Stub axle with double T-cross section |
| Capacity: 7,500KG |
| Rear: |
Single reduction with hub reduction and |
| Capacity: 13,000KG*2 |
| Brake system |
| Service: |
Full Air Brake, Dual circuit |
| Parking: |
Spring actuator at rear wheels |
| Auxiliary: |
Exhaust brake |
| Fuel Tank |
| Mounted on offside of the frame |
| Capacity: |
650L |
| Steering |
| Driving position: |
Right hand drive only |
| Suspension |
| Front suspension: |
Tapered leaf spring 9 semi-elliptic leaf springTapered leaf spring 9 semi-elliptic leaf springTapered leaf spring 9 semi-elliptic leaf spring |
| Rear suspension: |
Tapered leaf spring 12 semi-elliptic leaf springTapered leaf spring 12 semi-elliptic leaf springTapered leaf spring 12 semi-elliptic leaf spring |
| Clutch - Eaton |
| Type: |
Hydraulic control with air assisted |
| Dimensions (mm) |
| Overall dimension: |
6,800×2,500×3,150 |
| Kerb mass: |
9,090kg |
| Number of axle: |
3 |
| tread (mm): |
2,065/1,860/1,860 |
| Wheelbase (mm) |
3,200+1,350 |
| Min.Ground clearance (mm) |
255 |
| Crew |
3 |
| Payload |
| Axle load- MAN: |
Front: 7,500KG Rear: 2×13,000KG |
| Payload |
45,000KG |
| Calculated Performance |
| Max. Speed (km/h): |
110 |
| Max. Grade ability (%): |
30 |
| Min. turning radius (m): |
7 |
| Options |
| Including A/C, CD, THE FIFTH AXLE-JOST 90# |
| WABCO ABS, WORK PLATFORM DOME |
| IMPORT STEERING DEVICE. |
