Foton 904

Technical Specifications

Drive type 4*4
Wheelbase (mm) 2195
Track(front/rear) regulating method Step/stepless
Min.operating weight (without cab)(kg) 4155
Counterweight (max) (front/rear) 440/480
Theoretical speed of each gear(forward/reverse) 0.4-33.3/0.6-10.3;1.5-32.2/2.3-32.2;2.2-33.3/3.0-10.3;2.5-39.31/2.62-41.31
Engine type In-line, four-stroke
Cylinder number 4
Stroke 127
Engine rated power kW@rpm 66
Air cleaner type Dry or wet type
Max. Torque@ revolving speed (rpm) 315@1500~1700
Fuel tank capacity (L) 145
Type of steering gear Cycloid orbitrol steering gear
Clutch type dry type,double action
Gearbox shift mode Shift sleeve/synchro
Final transmission mode(front/rear) Single-stage spur gear type, outboard on both sides of the rear axle casing
Tire Model (front/rear) 12.4-24/18.4-30
Type of linkage Three point rear linkage
Lift capacity(610mm point))kN Ordinary Riser≥15;Forced Riser≥20
Type of PTO shaft Rear separated type
Outer diameter of PTO shaft spline φ35/φ38
Hydraulic output flow (L/min) 37/47
Overall dimension(L * W * H) 4530*2050*2810
Track(front/rear) 1610-1950/1608-1996
Min.Ground clearance(mm) 405
Min.operating weight (without cab)(kg) 3855
Gears(forward/reverse/creeper) 8+4/16+8 shuttle type /16+8 creeping/16+16
Brand Lovol
Intake mode Supercharged
Bore 100
Displacement(L) 4
Rated speed 2200
Type of cooling system Water-cooled (or water intercooling or air intercooling)
Specific fuel consumption at rated conditions (g/kW.h) ≤248
Type of steering system Hydraulic steering
Type of braking system Wet type, disc type, static hydraulic control
Gearbox type Two-axis mechanical gearbox
Type of central transmission Spiral bevel gear type
Frame type Frameless
Type of hydraulic suspension system Open-center, semi-separated or separated type
Linkage classes Class II
Regulating mode Semi-separated lifter: force and position combination control; Separated raiser:depth control and floating control
The number of PTO shaft splines 6 splines/8splines
PTO shaft speed 540/1000(760/1000,540/760;760/850)
  • The safety stand or cab is optional.
  • The second-generation or first-generation hood is optional.
  • The 11-inch or 12-inch LUK clutch is optional.
  • Dana, Kaichuang single-cylinder, Kaichuang double-cylinder or front axle is optional.
  • 16+8 shuttle gear, 16+8 crawling gear, 16+16 shuttle gear, 8+4 or 8+8 gear is optional.
  • The internal, external, internal & heightened or external & heightened air filter is optional.
  • The air brake is optional.
  • The multi-way valve is optional.
  • The ordinary or extreme pressure height limit lifter is optional.
  • The towing, trailing, towing & trailing is optional.
  • The two-level balance is optional.
